Uday Flanges stands out as a top-notch manufacturer and supplier of Inconel Threaded Flanges right inDubai, UAE. They’re well-known for producing high-performance flanges that can handle some seriously tough environments. Made from premium-grade Inconel alloys, these flanges boast impressive resistance to heat, oxidation, and corrosion. Perfect for high-pressure systems that don’t require welding, Uday Flanges makes sure that every product adheres to strict international standards and meets the specific needs of their clients. With a strong emphasis on quality, innovation, and timely delivery, the company caters to various industries, including aerospace, marine, chemical processing, and power generation, providing reliable and durable Inconel threaded flange solutions.
Inconel Threaded Flanges are mainly made up of nickel, chromium, and iron, with a dash of molybdenum, copper, titanium, and aluminum thrown in. This unique mix gives them fantastic mechanical strength, high-temperature stability, and remarkable corrosion resistance, even in harshly acidic and oxidizing conditions. These flanges can handle tensile strength over 758 MPa and yield strength around 340 MPa, keeping their integrity intact in temperatures that range from cryogenic levels all the way up to 980°C. Their special blend of toughness, resistance to stress-corrosion, and non-magnetic properties makes them perfect for critical and corrosive applications.
Uday Flanges, a leading supplier in Dubai, UAE, offers an extensive selection of Inconel Threaded Flangess, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
|---|---|
| Inconel Threaded / Screwed Flange Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Inconel Raised Face Threaded Flange Pressure Rating ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| ASTM B564 Inconel Threaded Flanges Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| ASME SB 564 Threaded Flange | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
| ASME SB564 Incoloy Alloyl Threaded Flange UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| B564 Threaded Flange EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| ASME SB564M Inconel Alloy Threaded Flange Production technique | Forged, Heat treated and machined |
| B564 Threaded Flange Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| ASME B564 Threaded Flange Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| ASTM B564 Inconel Threaded Flange Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Inconel Threaded Flange Origin | Indian / West Europe / Japan / USA / Korean |
| Manufacturer of Incoloy Threaded / Screwed Flange | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. ASTM B564 Threaded Flange: -BS Flange, EN Flange, API 6A Flange, ANSI Flange, ASME Flange, DIN Flange, EN1092-1 Flange, UNI Flange, JIS/ KS Flange, BS4504 Flange, GB Flange, AWWA C207 Flange, GOST Flange, PSI Flange B.S: BS4504 , BS3293, BS1560, BS10 DIN: DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638 ASTM B564 800 Incoloy Alloy Flanges |
| ASME SB564 Inconel Alloy Threaded Flange Uses & application | Bitumen upgraders. Heavy oil refineries. Nuclear power (mostly seamless). Petrochemicals and acids. |
| Inconel Threaded Plate Flanges Export to | Ireland, Singapore, Indonesia, Ukraine, Saudi & Arabia, Spain, Canada, USA, Brazil, Thailand, Korea, Iran, India, Egypt, Oman, Dubai, Peru, etc |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel Threaded Flanges | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensilee Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel Threaded Flanges | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
You’ll find Inconel Threaded Flanges being used in situations where welded connections just aren’t practical or safe. They’re commonly used in the oil & gas, petrochemical, marine, and power generation sectors, making them ideal for systems that transport highly corrosive or high-temperature fluids. These flanges are designed for easy installation and removal in piping systems, which is a big plus in maintenance-heavy environments. Their ability to resist pitting, cracking, and high-temperature oxidation makes them a go-to choice for offshore drilling rigs, exhaust systems, chemical reactors, and steam lines. Inconel threaded flanges deliver long-lasting reliability in both static and dynamic service conditions.
Yes, we offer custom sizes for Inconel Threaded Flanges to meet specific project needs. Our team at Uday Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@udayflanges.ae.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
