Uday Flanges,Dubai, UAE-based, is a reliable **ANSI B16.47 Flanges** manufacturer and supplier of high-performance solution for large-diameter piping systems in critical industrial processes. Catering to the oil & gas, power generation, petrochemical, and water infrastructure industries, Uday Flanges complies with ANSI, ASME, and global quality standards. With precision engineering, latest manufacturing technology, and strict testing, the organization ensures leak-proof, reliable flanges tolerant of high pressure, temperature, and corrosive service conditions.
**ANSI B16.47 Flanges** are for big-diameter flanges between 26″ and 60″ and are split into two series: Series A (previously MSS SP-44) and Series B (previously API 605). These flanges come in a range of materials such as carbon steel (A105), stainless steel (304/316), and alloy steel, with pressure ratings between Class 75 and Class 900. Mechanical properties depend on the material but typically cover high tensile and yield strength for heavy-duty industrial applications. These flanges come in types such as weld neck, blind, and custom configurations, which are made to provide strong mechanical performance and fit.
Uday Flanges, a premier supplier in Dubai, UAE, specializes in high-quality ANSI B16.47 Flanges, valued for their exceptional durability, corrosion resistance, precise engineering, and suitability across diverse industrial applications.
| pecifications | ANSI 16.47 Flanges |
|---|---|
| ANSI 16.47 Flange size range | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Main Types | Forged / Threaded / Screwed / Plate |
| Flange supporting material | Gasket, Ring Joint, Flange Bolts |
| Production technique | Forged, Heat treated and machined |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS JIS Threaded Flange, Socketweld Flange, Slip-On Flange, Blind Flange, Weld Neck Flange |
| Specialized manufacturer of | DIN 2566 en 1092 1 Pn16 Flange DIN 2566 pn16 Rtj Flange ANSI 16.47 Sorf Flange ANSI 16.47 Table Flanges DIN 2566 pn10 ANSI 16.47 Large Diameter Flange ANSI 16.47 Threaded Flanges ANSI 16.47 Blind Flanges ANSI 16.47 Plate Flanges ANSI 16.47 Weld Neck Flanges ANSI 16.47 Loose Flanges ANSI 16.47 Orifice Flanges ANSI 16.47 Slip-On Flanges ANSI 16.47 Lap Joint Flanges ANSI 16.47 Socketweld Flanges ANSI 16.47 AS 4087 Water Flanges |
| Test | Hydrostatic testing machine, Direct-reading Spectrograph,UI trasonic flaw detector, X-ray detector, Magnetic particle detector |
| Equipment | Bending machine, Press machine, electric bevelling machine, Pushing Machine, Sand-blasting machine etc |
| Origin | West Europe /Indian / USA / Japan / Korean |
| Key markets and industries for ANSI B16.47 Flange | Nuclear power (mostly seamless). Heavy oil refineries. Bitumen upgraders. Petrochemicals and acids. |
| Export to | Indonesia, Ireland, Ukraine, Singapore,Saudi Arabia,Canada, Peru, Dubai, Brazil, Iran, Korea, USA, India, Egypt, Thailand, Spain, Oman etc |
| ANSI B16.47 Flanges Application | To Connect Pipe & Tubes in Power, Petroleum,Construction, Chemical, Gas, Shipbuilding,Metallurgy, etc |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| Nominal Size | Outside Diameter (OD) | Min. Thickness [Note1] – WNF (tf) | Min. Thickness [Note1] – Blind (tf) | Length Through Hub (Y) | Hub Dia. Base [Note2] (X) | Hub Dia. Top (A) | Raised Face Dia. (R) | Drilling – Bolt Circle Dia. | Drilling- No. of Bolt Holes | Drilling – Dia. of Bolt Hole | Dia. of Bolt | Min. Fillet Radius (r1) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 26 | 38.25 | 3.50 | 3.88 | 7.62 | 28.62 | 26.00 | 29.50 | 34.50 | 28 | 178 | 134 | 0.44 |
| 28 | 40.75 | 3.75 | 4.12 | 8.12 | 30.81 | 28.00 | 31.50 | 37.00 | 28 | 2 | 178 | 0.50 |
| 30 | 43.00 | 4.00 | 4.38 | 8.62 | 32.94 | 30.00 | 33.75 | 39.25 | 28 | 218 | 2 | 0.50 |
| 32 | 45.25 | 4.25 | 4.56 | 9.12 | 35.00 | 32.00 | 36.00 | 41.50 | 28 | 218 | 2 | 0.50 |
| 34 | 47.50 | 4.38 | 4.81 | 9.50 | 37.19 | 34.00 | 38.00 | 43.50 | 28 | 218 | 2 | 0.56 |
| 36 | 50.00 | 4.50 | 5.06 | 9.88 | 39.38 | 36.00 | 40.25 | 46.00 | 32 | 218 | 2 | 0.56 |
| 38 | 47.50 | 4.88 | 4.88 | 8.12 | 39.50 | 38.00 | 40.75 | 44.00 | 32 | 178 | 134 | 0.56 |
| 40 | 50.00 | 5.12 | 5.12 | 8.50 | 41.50 | 40.00 | 43.00 | 46.25 | 32 | 2 | 178 | 0.56 |
| 42 | 52.00 | 5.25 | 5.25 | 8.81 | 43.62 | 42.00 | 45.00 | 48.25 | 32 | 2 | 178 | 0.56 |
| 44 | 54.50 | 5.50 | 5.50 | 9.18 | 45.62 | 44.00 | 47.25 | 50.50 | 32 | 218 | 2 | 0.56 |
| 46 | 56.75 | 5.75 | 5.75 | 9.62 | 47.75 | 46.00 | 49.50 | 52.75 | 36 | 218 | 2 | 0.56 |
| 48 | 59.50 | 6.00 | 6.00 | 10.12 | 49.88 | 48.00 | 51.50 | 55.25 | 28 | 238 | 214 | 0.56 |
| 50 | 61.75 | 6.19 | 6.25 | 10.56 | 52.00 | 50.00 | 53.62 | 57.50 | 32 | 238 | 214 | 0.56 |
| 52 | 63.75 | 6.38 | 6.44 | 10.88 | 54.00 | 52.00 | 55.62 | 59.50 | 32 | 238 | 214 | 0.56 |
| 54 | 67.00 | 6.69 | 6.75 | 11.38 | 56.12 | 54.00 | 57.88 | 62.25 | 28 | 258 | 212 | 0.56 |
| 56 | 69.00 | 6.88 | 6.94 | 11.75 | 58.25 | 56.00 | 60.12 | 64.25 | 32 | 258 | 212 | 0.56 |
| 58 | 71.00 | 7.00 | 7.12 | 12.06 | 60.25 | 58.00 | 62.12 | 66.25 | 32 | 258 | 212 | 0.56 |
| 60 | 74.25 | 7.31 | 7.44 | 12.56 | 62.38 | 60.00 | 64.38 | 69.00 | 32 | 278 | 234 | 0.56 |
Yes, we offer custom sizes for ANSI B16.47 Flanges to meet specific project needs. Our team at Uday Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@udayflanges.ae.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
