Uday Flanges is a trustworthy producer and distributor of superior quality flanges. With specialization in a large variety of flanges they provide strong and trustworthy solutions across many industrial processes. Amongst their products Carbon Steel Slip On Flanges are famous for being easy to install and long-lasting. These flanges are specifically formulated to satisfy the stringent demands of pipeline systems providing durability and integrity in use in construction, the oil and gas sector and the petrochemical sector.
**Carbon Steel Slip On Flanges** are normally manufactured from grades like ASTM A105, A350 LF2, and A516. The materials have superior mechanical properties with tensile strength between 415 and 620 MPa and possess good ductility, weldability, and toughness. Slip on flanges are used to slip over the pipe and are held in place by fillet welds on both the inside and outside of the flange, producing a secure and leak-free connection. Their flat or raised face design accommodates multiple types of gaskets and is utilized in low to medium pressure systems where rapid assembly and alignment are advantageous.
| Specification | ASTM A694 / ASME SA105 |
|---|---|
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MCarbon S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| PRESSURE Rating ANSI | Class 150 LBS, 300 LBS, a105 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| PRESSURE Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production Technique | Forged, Heat treated and machined |
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Precarbon-steel machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Manufacturer of | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. BS Flange, EN Flange, API 6A Flange, ANSI Flange, ASME Flange, DIN Flange, EN1092-1 Flange, UNI Flange, JIS/ KS Flange, BS4504 Flange, GB Flange, AWWA C207 Flange, GOST Flange, PSI Flange B.S: BS4504 , BS3293, BS1560, BS10 DIN: DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638 ASTM A694 Lf2 Carbon Steel Flanges |
| Grades | Carbon Steel a105, Lf2, f42, f52, f56, f60, f65, f70, f80, A36, IS2062 |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Uday Flanges, a leading supplier in Dubai, UAE, offers an extensive selection of Carbon Steel Slip On Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
**Carbon Steel Slip On Flanges** find extensive applications in industrial piping systems that transport water, steam, gas, oil, and air. Fire protection systems, plumbing networks, cooling systems, oil refineries, and chemical plants are typical applications. Their easy fabrication and suitability for frequent maintenance or inspection make them perfect for systems where they need to be carried out regularly. Slip on flanges provide fabrication and labor cost savings, and their medium-pressure rating makes them ideal for general service piping. With the availability of optional coatings or galvanizing, they also find use in mildly corrosive situations with a longer service life.
| ASME/ANSI B 16.5 | Slip on Flange |
| PRESSURE CLASS | 150, 300, a105, a105, 900, 1500, 2500 |
| ASME/ANSI B 16.47 | Blind Flange [Series A & B],Welding Neck Flange |
| PRESSURE CLASS | 75, 150, 300, a105, a105, 900 |
| ASME/ANSI B 16.36 | Slip on Flange |
| PRESSURE CLASS | 300, a105, a105, 900, 1500, 2500 |
| PRESSURE CLASS | PN 2.5 TO PN 40 |
| BS 4504[PART 1] | Hubbed Slip-On |
| PRESSURE CLASS | PN 2.5 TO PN a105 |
| BS 1560 BOCarbon | Hubbed Slip-On Hubbed Threaded |
| PRESSURE CLASS | 150, 300, a105, a105, 900, 1500, 2500 |
| BS10 | Plate Slip-On Flange, Slip-On Bocarbon-steel Flange |
| TABLE | D, E, F, H |
| DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
| PRESSURE CLASS | PN 6 TO PN 100 |
Yes, we offer custom sizes for Carbon Steel Slip On Flanges to meet specific project needs. Our team at Uday Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@udayflanges.ae.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
