Uday Flanges, aDubai, UAE-based company, is a reliable manufacturer and supplier of **DIN 2565 PN6 Threaded Flanges** that provides affordable and efficient solutions for low-pressure piping systems. Dedicated to catering to industries like water treatment, HVAC, compressed air networks, and general plumbing, Uday Flanges manufactures threaded flanges that conform to DIN and international standards. With accurate machining, quality materials, and stringent inspection procedures, the company produces durable, corrosion-resistant flanges that ensure easy installation and maintenance in low-pressure systems.
**DIN 2565 PN6 Threaded Flanges** are used in systems with a nominal pressure of 6 bar (87 psi) and are usually made of carbon steel, stainless steel, or ductile iron. They have internal threads and can thus be screwed onto externally thread pipes—suited for situations in which welding is not an option or desirable. Appropriate for DN10 to DN100 pipe sizes, these flanges offer moderate strength and high resistance to corrosion as long as the proper material is chosen. They are simple to assemble and disassemble, making them perfect for applications where frequent inspection or replacement is necessary.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Neck | Raised face | Screws | Weight (7,85 Kg/dm3) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | Thread | D | b | k | h1 | d3 | d4 | f | Holes | Thread | d2 | Kg | |
| 15 | 21,3 | R 1/2 | 80 | 12 | 55 | 20 | 30 | 40 | 2 | 4 | M 10 | 11 | 0,373 |
| 20 | 26,9 | R 3/4 | 90 | 14 | 65 | 24 | 40 | 50 | 2 | 4 | M 10 | 11 | 0,59 |
| 25 | 33,7 | R 1 | 100 | 14 | 75 | 24 | 50 | 60 | 2 | 4 | M 10 | 11 | 0,743 |
| 32 | 42,4 | R 1 1/4 | 120 | 14 | 90 | 26 | 60 | 70 | 2 | 4 | M 12 | 14 | 1,05 |
| 40 | 48,3 | R 1 1/2 | 130 | 14 | 100 | 26 | 70 | 80 | 3 | 4 | M 12 | 14 | 1,2 |
| 50 | 60,3 | R 2 | 140 | 14 | 110 | 28 | 80 | 90 | 3 | 4 | M 12 | 14 | 1,37 |
| 65 | 76,1 | R 2 1/2 | 160 | 14 | 130 | 32 | 100 | 110 | 3 | 4 | M 12 | 14 | 1,92 |
| 80 | 88,9 | R 3 | 190 | 16 | 150 | 34 | 110 | 128 | 3 | 4 | M 16 | 18 | 2,82 |
| 100 | 114,3 | R 4 | 210 | 16 | 170 | 38 | 130 | 148 | 3 | 4 | M 16 | 18 | 3,19 |
| 125 | 139,7 | R 5 | 240 | 18 | 200 | 40 | 160 | 178 | 3 | 8 | M 16 | 18 | 4,47 |
| 150 | 165,1 | R 6 | 265 | 18 | 225 | 44 | 185 | 202 | 3 | 8 | M 16 | 18 | 5,3 |
Uday Flanges, a leading supplier in Dubai, UAE, offers an extensive selection of DIN 2565 PN6 Threaded Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Yes, we offer custom sizes for DIN 2565 PN6 Threaded Flanges to meet specific project needs. Our team at Uday Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@udayflanges.ae.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| DIN 2565 PN6 Threaded Flanges Supplier in Dubai | Alloy Steel DIN 2565 PN6 Threaded Flanges Manufacturer in UAE |
| DIN 2565 PN6 Screwed Flange Stockist in UAE | Raised Faced DIN 2565 PN6 Slip-On flanges Dealer in Sharjah |
| ASME SA105N Raised Faced DIN 2565 PN6 Threaded Flanges | 18 inch Carbon Steel DIN 2565 PN6 Threaded Flange |
| Stainless Steel DIN 2565 PN6 Threaded Flange | ASTM B564 Raised Faced DIN 2565 PN6 Threaded Flanges |
| Carbon Steel Raised Face DIN 2565 PN6 Screwed Flange Stockist | Duplex Steel DIN 2565 PN6 Threaded Flanges Supplier in mm |
| DIN 2565 PN6 Threaded Flange Dimensions | Raised Face DIN 2565 PN6 Threaded Flange Manufacturer |
| Carbon Steel DIN 2565 PN6 Threaded Flange | DIN 2565 PN6 Threaded RF Flange Supplier |
| DIN 2565 PN6 Threaded Flanges Distributor in Jebel Ali | Flat Face DIN 2565 PN6 Threaded Flanges Exporter |
| DIN 2565 PN6 Threaded Flange Manufacturer | Flat Face DIN 2565 PN6 Screwed Flange Manufacturer |
| 30 inch DIN 2565 PN6 Threaded Flange Dealer | Raised Face DIN 2565 PN6 Threaded Flanges Manufacturer |
| 18 inch DIN 2565 PN6 Carbon Steel Threaded Flange | DIN 2565 PN6 Threaded Flange Dimensions in mm |
| 8 Inch DIN 2565 PN6 Threaded Pipe Flanges | DIN 2565 PN6 Threaded Flanges Stockist |
| Alloy Steel DIN 2565 PN6 Threaded Flanges | Copper Nickel DIN 2565 PN6 Threaded Flanges at Best Price |
| Nickel Alloy DIN 2565 PN6 Threaded Flange | Mild Steel DIN 2565 PN6 Threaded Flange |
| DIN 2565 PN6 Screwed Flanges Supplier in Abu Dhabi | MS DIN 2565 PN6 Threaded Flange |
| DIN 2565 PN6 Threaded Flange Exporter | DIN 2565 PN6 Threaded Flange Pressure Ratings |
| DIN 2565 PN6 Large Diameter Threaded Flange | 30 Inch DIN 2565 PN6 Threaded Pipe Flange Dimensions |
| Raised Face DIN 2565 PN6 Threaded Plate Flanges | Titanium DIN 2565 PN6 Threaded Flanges |
| 4 inch Stainless Steel DIN 2565 PN6 Threaded Flange | DIN 2565 PN6 Screwed RF Flanges Stockholder |
| DIN 2565 PN6 Threaded FF Flange Supplier | Suppliers of DIN 2565 PN6 Threaded Flange |
| DIN 2565 PN6 Threaded Pipe Flanges Supplier in Al Ain | Duplex Steel DIN 2565 PN6 Threaded Flanges |
| German Standard DIN 2565 PN6 Threaded Flanges | DIN 2565 PN6 Threaded Flange Supplier in UAE |
| DIN 2565 PN6 Threaded Pipe Flanges Wholesaler | DIN 2565 PN6 Threaded Flanges Supplier |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
