Hastelloy Forged Flanges are top-notch components made from high-quality Hastelloy alloys, celebrated for their remarkable resistance to corrosion and harsh chemicals. These flanges are crafted through a forging process that boosts their strength and improves their grain structure, making them perfect for tough environments where reliability and durability are a must. They ensure a secure, leak-proof connection in piping systems, especially when dealing with high pressure and temperature. Thanks to their outstanding metallurgical properties, Hastelloy Forged Flanges are the go-to choice in critical industries that frequently encounter oxidizing and reducing agents, guaranteeing a long service life with minimal maintenance.
These flanges are made from nickel-based alloys, primarily featuring Nickel (58–63%), Molybdenum (up to 30%), Iron (4–7%), and Chromium (14.5–16%). This special blend gives them exceptional resistance to pitting, stress corrosion cracking, and crevice corrosion. On the mechanical side, they boast a tensile strength of up to 790 MPa, a yield strength of around 355 MPa, and an elongation of about 30%. They also excel in weldability and formability, standing up to extreme thermal and chemical stresses. Their high performance in both oxidizing and reducing environments makes them perfect for severe service conditions.
| B564 Gr Flange Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
|---|---|
| Hastelloy Alloy Flange Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Alloy Grade Flange Pressure Rating ANSI | Class 150 LBS, 300 LBS, LBS, 900 LBS, 1500 LBS, 2500 LBS |
| ASTM B564 Hastelloy Flanges Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| ASME SB 564 Flange | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
| ASME SB564 Hastelloy Alloy Flange UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| B564 Flange EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Most common types of ASTM B564 Hastelloy Flange | Forged / Threaded / Screwed / Plate |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| ASME SB564M Alloy Flange Production technique | Forged, Heat treated and machined |
| B564 Grade Flange Connect Type/ Flange Face Type | Hastelloy Forged Flanges |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| ASME B564 Nickel Alloy Flange Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| ASTM B564 Alloy Flange Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Manufacturer of Hastelloy Alloy ASTM B564 Flange | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. ASTM B564 Flange: -BS Flange, EN Flange, API 6A Flange, ANSI Flange, ASME Flange, DIN Flange, EN1092-1 Flange, UNI Flange, JIS/ KS Flange, BS4504 Flange, GB Flange, AWWA C207 Flange, GOST Flange, PSI Flange B.S: BS4504 , BS3293, BS1560, BS10 DIN: DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638 ASTM B564 Hastelloy Flanges |
| ASME SB564M Hastelloy Flange Uses & application | Bitumen upgraders. Heavy oil refineries. Nuclear power (mostly seamless). Petrochemicals and acids. |
Uday Flanges, a leading supplier in Dubai, UAE, offers an extensive selection of Hastelloy Forged Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Hastelloy Forged Flanges find their place in various industries, including chemical processing, aerospace, marine, nuclear, and pharmaceuticals, where exposure to highly corrosive substances is a regular occurrence. They are ideal for connecting pipes, valves, pumps, and other equipment in systems that handle aggressive chemicals, high-temperature fluids, or gases. Common uses include reactors, heat exchangers, distillation columns, and pressure vessels. Because of their superior resistance to a wide range of corrosive media, Hastelloy flanges are also utilized in flue gas scrubbers, sulfuric acid plants, and wastewater treatment facilities, where performance and reliability are absolutely essential.
