Uday Flanges is a reputable manufacturer and supplier located inDubai, UAE, focusing on the production and distribution of top-notch JIS B2220 5K Flanges. With a strong dedication to meeting international standards, Uday Flanges delivers flanges that are not only durable but also dimensionally precise, catering to a variety of industrial needs. These JIS B2220 5K Flanges are crafted from high-quality raw materials and cutting-edge engineering techniques, ensuring outstanding performance and reliability. Uday Flanges serves a wide range of industries, including oil & gas, petrochemicals, and water treatment plants, providing timely deliveries and competitive pricing to satisfy the increasing demands of clients both in the USA and beyond.
Typically, JIS B2220 5K Flanges are made from carbon steel, stainless steel, or alloy steel, depending on their intended use. They are rated for a pressure class of 5K (5 kg/cm²) and adhere to the Japanese Industrial Standard (JIS). These flanges boast impressive tensile strength, toughness, and resistance to corrosion and thermal stress. They maintain their dimensional stability and integrity under low to moderate pressure and temperature conditions. Their robust mechanical strength, along with the ease of welding and installation, makes them perfect for piping systems where durability and consistent performance are crucial.
Uday Flanges, a leading supplier in Dubai, UAE, offers an extensive selection of JIS B2220 5K Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Size | (1/2″) To (48″) |
|---|---|
| Standards | 5K, 10K, 40K, 16K 20K 30K, 63K |
| Size Of Bore Diameter Flange | NPS ≤ 10 |
| Standard Dimensions | EN-1092, ASME B16.48, API605, BS4504, EN1092, UNI, ISO, API7S-43, ANSI/ASME B16.5, API7S-15, MSS S44, IS 2062, ASME B16.36, DIN, AWWA C207, B16.47 Series A & B, BS1560-3.1, ISO70051, API. |
| Minimum Pressure | 150# To 2500# |
| Flange Face Type Manufacturer | Raised Face, Groove And Small Tongue Groove, RTJ, Flat Face, Large Tongue & Large Male-Female And Small Male-Female, Lap-Joint Face. |
| Top Six Type Of Flange | Threaded Flange, Lap Joint Flange, Socket-Weld Flange, Blind Flange, Slip-On Flange, Weld Neck Flange |
| Standard Materials | Duplex Steel & Super Duplex Steel, Copper Nickel, Inconel, Mild Steel, Stainless Steel, Hastelloy, Alloy Steel, Carbon Steel. |
| Thickness Length | NPS ≤ 18 |
| Manufacturing Process | Forged/ Machined/ Heat Treated |
| Other Type Of Flange | Forged/ Plate/ Threaded |
| JIS B2220 5k | LTB | DRILLING | |||||||
|---|---|---|---|---|---|---|---|---|---|
| NPS | O.D. OF FLANGE | FLANGE THIKNESS | THIKNESS OF BLRF | BOSSED LENGTH SOH.SW LI | WN LENGTH | DIAMETER OF PITCH CIRCLE | BOLT HOLES NUMBER | DIAMETER BOLT HOLE | |
| MILLIMETER | IN. | C | T | T1 | L | L1 | PCD | # | H |
| 10 | 3/8 | 75 | 9 | 9 | 13 | 24 | 55 | 4 | 12 |
| 15 | 1/2 | 80 | 9 | 9 | 13 | 25 | 60 | 4 | 12 |
| 20 | 3/4 | 85 | 10 | 10 | 15 | 28 | 65 | 4 | 12 |
| 25 | 1 | 95 | 10 | 10 | 17 | 30 | 75 | 4 | 12 |
| 32 | 1 1/4 | 115 | 12 | 12 | 19 | 33 | 90 | 4 | 15 |
| 40 | 2 1/2 | 120 | 12 | 12 | 20 | 34 | 95 | 4 | 15 |
| 50 | 2 | 130 | 14 | 14 | 24 | 36 | 105 | 4 | 15 |
| 65 | 2 1/2 | 155 | 14 | 14 | 27 | 39 | 130 | 4 | 15 |
| 80 | 3 | 180 | 14 | 14 | 30 | 41 | 145 | 4 | 19 |
| 90 | 3 1/2 | 190 | 14 | 14 | N/A | 41 | 155 | 4 | 19 |
| 100 | 4 | 200 | 16 | 16 | 36 | 41 | 165 | 8 | 19 |
| 125 | 5 | 235 | 16 | 16 | 40 | 43 | 200 | 8 | 19 |
| 150 | 6 | 265 | 18 | 18 | 40 | 49 | 230 | 8 | 19 |
| 175 | 7 | 300 | 18 | 18 | N/A | 49 | 260 | 8 | 23 |
| 200 | 8 | 320 | 20 | 20 | N/A | 53 | 280 | 8 | 23 |
| 225 | 9 | 345 | 20 | 20 | N/A | 54 | 305 | 12 | 23 |
| 250 | 10 | 385 | 22 | 22 | N/A | 61 | 345 | 12 | 23 |
| 300 | 12 | 430 | 22 | 22 | N/A | 62 | 390 | 12 | 23 |
| 350 | 14 | 480 | 24 | 24 | N/A | 73 | 435 | 12 | 25 |
| 400 | 16 | 540 | 24 | 24 | N/A | 76 | 495 | 16 | 25 |
| 450 | 18 | 605 | 24 | 24 | 40 | 79 | 555 | 16 | 25 |
| 500 | 20 | 655 | 24 | 24 | 40 | 79 | 605 | 20 | 25 |
| 550 | 22 | 720 | 26 | 26 | 42 | 81 | 665 | 20 | 27 |
| 600 | 24 | 770 | 26 | 26 | 44 | 81 | 715 | 20 | 27 |
| 650 | 26 | 825 | 26 | 28 | 48 | 85 | 770 | 24 | 27 |
| 700 | 28 | 875 | 26 | 30 | 48 | 94 | 820 | 24 | 27 |
| 750 | 30 | 945 | 28 | 32 | 52 | 100 | 880 | 24 | 33 |
| JIS b2220 Standard | JIS b2220 Class | Diameter Of JIS | Bolt Circle Diameter | No. of Bolts | Size Of Bolt | Bolt Hole Diameter |
|---|---|---|---|---|---|---|
| AS4087 Flanges | PN14 Flanges | 95 | 67 | 4 | M12 | 14 |
| AS 2129 Flange | Table C Flanges | 95 | 67 | 4 | 13 | 14 |
| Table D Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table E Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table F Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table H Flanges | 114 | 83 | 4 | 16 | 17 | |
| Table J Flanges | 114 | 83 | 4 | 16 | 17 | |
| ANSI B16.5 Flanges | ANSI 150 Flanges | 89 | 60 | 4 | 13 | 16 |
| ANSI 300 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 600 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 900 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ANSI 1500 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ISO 7005 (DIN) Flange | PN6 Flanges | 80 | 55 | 4 | M10 | 11 |
| PN10 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN16 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN20 Flanges | 90 | 60.5 | 4 | M14 | 16 | |
| PN25 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN40 Flanges | 95 | 65 | 4 | M12 | 14 |
JIS B2220 5K Flanges find extensive use in low-pressure piping systems across various industries. Common applications include water distribution, drainage, HVAC systems, and chemical processing. They are particularly well-suited for non-aggressive fluids like water, steam, and gases. Their standardized design guarantees compatibility with JIS-compliant systems, making them ideal for marine, power generation, and food processing sectors. These flanges are prized for their leak-proof connections, corrosion resistance, and ease of maintenance, making them a reliable and cost-effective choice for both new installations and the upkeep of existing pipelines.
Yes, we offer custom sizes for JIS B2220 5K Flanges to meet specific project needs. Our team at Uday Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@udayflanges.ae.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
